Scientific planning of cleaning routes
Scientific planning of cleaning routes
Real-time Positioning and Mapping
Consequat at a a class nascetur cursus amet placerat congue nisl.
Smart Features
Automatic zoning feature + Room naming;
Permanent virtual wall feature
Map Selection Feature
Can save up to 10 maps, eliminating the need to rebuild maps when moving the robot in a duplex structure home, which enhances cleaning efficiency;
APP supports drawing and autonomous libosHome
Available In All Environments
Various home environments, ground types can be used with confidence
– Marble –
– Wood –
– Tile –
– Carpet –
Ultra-Thin and Dynamic
9.9cm ultra-thin body, easily access furniture beneath beds;
18mm obstacle clearance capability, easily cross thresholds.
Precise Navigation
Utilize LDS laser navigation for intelligent planning of efficient cleaning paths.
Powerful Cleaning System
6000Pa powerful suction with four suction power settings.
Equipped with a high-performance brushless motor for long-lasting and stable power.
600ml large-capacity dustbin with H11 HEPA filter to trap fine dust.
2600mAh/5200mAh high-capacity battery ensures prolonged runtime.
Specification
G580 Specification Sheet
| G580 Specification Sheet | |||
| Technical Type | Laser | ||
| Overview | Model | G580 | |
| Customer Logo | Customized | ||
| Main Body Color | Customized | ||
| Package Contents | Main Unit ×1；Charging Dock ×1；Adapter ×1；Remote Control ×1；Mop Cloth ×2 (one installed on the unit, one spare in the box)；Side Brush ×2；HEPA Filter ×2 (one installed in the dustbin, one spare in the box) | ||
| Detailed Parameters | |||
| Appearance Parameters | Color | Optional | |
| Main Unit Dimensions (D × H)mm | 330mm*100mm (including wheel height) | ||
| Main Unit Material | ABS+PC (heat resistant up to 750°) | ||
| Net Weight（kg） | 3.1KG | ||
| Gross Weight (1-in-1 carton) | 5.0KG | ||
| Color Box Dimensions (L × W × H)mm | 350x190x428mm | ||
| Buttons | Silver | ||
| Glass Panel | Plastic | ||
| Decorative Ring | Silver | ||
| Side Brush Color | Gray | ||
| Dustbin Color | BLue | ||
| Roller Brush Cover Color | Black | ||
| Roller Brush Shaft Color | Black | ||
| Other Parameters | Laser Sensor | 360°，6m | |
| Sensors | 21PCS | ||
| Fan | Domestic, DC brushless | ||
| Side Brush / Wheel / Main Brush Motors | Standard, DC brushed | ||
| Control Panel | Physical switch | ||
| Cleaning Time（min） | ~180 min | ||
| Recharge Time（min） | Recharges at ~20% battery | ||
| Charging Time（H） | ~5-6 | ||
| Operating Noise (dB) | 60/68/74/78 | ||
| Operating Temperature / Humidity | 0-40℃ 85/% | ||
| Threshold Crossing Height（mm） | 18mm | ||
| Rated Power (Main Unit)（W） | 25W | ||
| Vacuum Suction (Pa) | 2700/6000（optional） | ||
| Water Tank Capacity（ml） | 250ml | ||
| Dustbin Capacity（ml） | 350ml | ||
| Functions | Anti-drop Function | Supported | |
| App Smart Control | Supported | ||
| OTA Updates | Supported | ||
| Real-time Mapping | Supported | ||
| Map Storage | Up to 5 maps | ||
| Zoned Cleaning | Supported | ||
| App No-go Zones | Supported | ||
| Scheduled Cleaning | Supported | ||
| Water Tank Control | Electric, 3 levels | ||
| Vacuum & Mop Combo | Interchangeable water tank / dustbin | ||
| Virtual Wall | Supported | ||
| Resume Cleaning After Charging | Supported | ||
| Room Naming | Supported | ||
| AI Smart Speaker Connection | Supported | ||
| Carpet Detection | Not supported | ||
| Bluetooth Smart Networking | Supported | ||
| UV Sterilization | Not supported | ||
| 配件 | Battery | Brand | GanFeng |
| Type | Lithium-ion | ||
| Capacity | 2600mAh | ||
| Nominal Voltage | 14.6V | ||
| Charging Voltage | 16.8V | ||
| Adapter | Input | AC 100～240V，50/60Hz，0.6A | |
| Output | 19.0V/（0.6A） | ||
| Charging Dock | Input Voltage/Current | 19.0V/0.6A | |
| Output Voltage/Current | 19.0V/（0.6A） | ||
| Dimensions | 166*146*79mm | ||
| Side Brush | Bristle Length(mm) | 70mm | |
| Quantity | 4 pcs (2 installed, 2 spare in package) | ||
| Roller Brush | Bristle Length(mm) | 12mm | |
| Cleaning Tool | Bird-shaped Brush with Blade | yes | |
| Primary Filter | Material | HEPA | |
| HEPA Filter | Grade | H11 | |
| HEPA + Filter Net | Grade | HEPA + Filter Sponge, PE band packaging | |
| Remote Control | without screen | Optional | |
| Safety & Certification | CE、FCC、ROHS | ||
