    X500

Your Smart Home Partner

identify-environment

route planning

Scientific planning of cleaning routes

Scientific planning of cleaning routes

positioning

positioning

Real-time Positioning and Mapping

Consequat at a a class nascetur cursus amet placerat congue nisl.

arch-shape-cleaning

arch shape cleaning

S Shape Cleaning

Arch shape cleaning(The second generation gyroscope navigation to efficiently finish the cleaning order.

  • Cleaning your whole house

    Especially the blind areas and corner

  • 2 in 1 Cleaning Sweeping & Mopping

    Sweep the debris firstly and then mop the dust deeply.

Intelligent Double Programming, Sweeping and Mopping More Efficient

  • product structure
  • product structure
  • product structure
  • product structure
  • product structure
  • product structure
123456

Low Repeation Plan First Then Clean

Cleaning route in an arch shape and remember the coordinate point at the real-time, never go back to improve the efficiency of cleaning.

low repeation

Available In All Environments

Various home environments, ground types can be used with confidence

marble

– Marble –

wood

– Wood –

tile

– Tile –

carpet

– Carpet –

  • Voice Function

    English voice assistance tells you what it is doing or if it requires attention

Automatic Recharge and Resume

Automatically recharges itself and resumes until the job is done.
It with VSLAM Navigation to help robot seamlessly and efficiently navigate an entire level of your home and keep track of its location.

Anti-collision

Cliff sensors keep the robot from falling off stairs

Anti-collision

All-around anti-collision sensors with bumper allows the robot toavoid barriers and adjust its route timely to protect your furniture

Efficient obstacle

Easily overcome obstacles up to 15mm an 15° slope

  • low noise

    Brushless motor work in with scientific design of wind duct to reduce the noise an windage

  • Geomagnetic sensor build the virtual wall function

    Boundary Markers let you decide where your robot can go and where it should”keep out

Power On/Off .1

Display Screen .2

Auto Cleaning .3

Return For Auto Charging .4

Confirm .5

Direction .6

1
2
3
4
5
6
7
8
9
10
11
12
remote control
1

Power On / Off

2

Display Screen

3

Auto Cleaning

4

Return For Auto Charging

5

Confirm

6

Direction

7

Suction Settings

8

Clock Settings

9

Single Room Cleaning

10

Mopping Model

11

Schedule Setting

12

Edge Cleaning

7. Suction Settings

8. Clock Settings

9. Single Room Cleaning

10. Mopping Model

11. Schedule Setting

12. Edge Cleaning

  • Easily controlled by APP, Compatible with Amazon Alexa and Google Home

    google-playapple-store

Specification

Fusce fermentum a sagittis vestibulum vestibulum hac at parturient convallis facilisi

X500 Specification
Overview model x500
Appearance (design drawing)
Detailed parameters Remark
Appearance color Hanyu White/Black/Gray
Host size (diameter * height) mm 330mm*75mm
Bottom shell material Black ABS
Face shell/front impact Hanyu White ABS
face cover Pearl white with silver powder
LED display White light
Button color White gray silicone
Main functions Recharge mode Automatic recharge
Working Mode Planning mode, appointment mode, edge cleaning mode, key cleaning mode, mopping mode
Cleaning time (min) 120in（2600mAh） Default gear 800pa
Recharge time (min) 30min
Charging time (min) 4-6 hours
Operating noise (db) 65db (default setting 800pa)
Operating temperature and humidity range (℃/%) 0-40℃  85/%
Walking speed (cm/s) 25
Height across threshold (mm) 15
Vacuum suction value (pa) 2700/6000pa (Optional)
Your App
Adjustable suction 4 gears adjustable 800/1200/2700/6000Pa
Adjustable water tank Three gears adjustable
Main components Dust box Dust box volume (ml) Colorless and transparent 600ml (single dust box) Upper cover/lower cover colorless and transparent
Primary filter Material HAPA paper Hanyu white mesh frame/dust box button Hanyu white
Secondary filter Filter grade semi-HEPA (ASAHI KASEI E01070)
screw Lock bottom shell, bumper bottom, roller brush cover, battery cover, dust box, side brush box screws Black galvanized 48H salt spray test
Roller brush cover Black Gray-black
Main brush flocking Straight hair Straight hair
rag quantity 2pcs
Dimensions (length * width * height) mm 295mm*100.5mm*4mm
water tank Water tank capacity (ml) 350mm Transparent blue
tire New tire tread New tread
side brush Edge bristle length (mm) 70
Wi-Fi module Wi-Fi module Tuya WiFi module
Charging station Voltage/Current 19.0V/0.6A
Battery  Battery Type lithium-ion batteries
Battery capacity (mAh) Ganfeng 2600mAh 14.4V
adapter Input parameters AC 100～240V，50/60Hz，0.6A
Output Parameters 19.0V/0.6A
Side brush motor Side brush motor 2pcs DC/12V carbon brush motor
Main brush motor Main brush motor 1pcs DC/12V carbon brush motor
Side wheel motor Drive wheel motor 2pcs DC/12V carbon brush motor
fan motor fan motor 1pcs DC/14.4V brushless motor
Ground inspection components Anti-fall detection 4 groups of infrared anti-drop ≥10cm
Planning Module Gyroscope sensor Epson
Machine Sensing Anti-collision mechanical sensor 2pcs photoelectric switch
Infrared anti-collision Anti-collision electronic sensors 7 sets of infrared sensors
Infrared receiver Infrared receiving sensor 6 sets of infrared receiving sensors
Package Packaging materials Provided by the customer
Certification 3C certification （3C）
RoHS               RoHS
Download

icon pdfDownload X500 Specification
